IR Wire Guide Rollers
Series overview
- Models
- 6
- Dimension range
- 6 - 250 mm0.236 - 9.84 in
- Materials
- Wire
- Tube
- Cable
- Capabilities
- Adjustable rolls
Shared across the series
- Individually adjustable rollers
- Handwheel adjustment
- Four configurations (A–D)
How to choose a model
A few checks narrow the IR models below to the ones worth quoting.
- Reading the dimensions
- The Dimensions column lists the size range, meaning the diameter or thickness of the material, that each model is specified for. For example, IR 6 covers up to 6.0 mm.
- Match the material
- Every IR model is listed for wire, tube and cable, so material does not separate models within this series. Use size and roll count to narrow the choice.
- Match the size
- Pick the model whose range contains the diameter or thickness of your material. The IR series spans 6 - 250 mm (0.236 - 9.84 in) in total. If your size sits on the boundary between two models, ask us which suits your material better.
Tolerance and line speed also affect the right choice. Send your material, size, tolerance and line speed with your quote request and our engineers will confirm the model.
Models in this series
Compare dimension ranges and processing capabilities, then add the models you need to a quote request.
| Model | Dimensions | Materials | Capabilities | Request a quote |
|---|---|---|---|---|
| IR 6 up to 6.0 mm Wire, Tube, Cable · Adjustable rolls | up to 6.0 mm | Wire, Tube, Cable | Adjustable rolls | |
| IR 12 up to 12.0 mm Wire, Tube, Cable · Adjustable rolls | up to 12.0 mm | Wire, Tube, Cable | Adjustable rolls | |
| IR 50 6.0 - 50.0 mm Wire, Tube, Cable · Adjustable rolls | 6.0 - 50.0 mm | Wire, Tube, Cable | Adjustable rolls | |
| IR 100 10.0 - 100.0 mm Wire, Tube, Cable · Adjustable rolls | 10.0 - 100.0 mm | Wire, Tube, Cable | Adjustable rolls | |
| IR 160 20.0 - 160.0 mm Wire, Tube, Cable · Adjustable rolls | 20.0 - 160.0 mm | Wire, Tube, Cable | Adjustable rolls | |
| IR 250 50.0 - 250.0 mm Wire, Tube, Cable · Adjustable rolls | 50.0 - 250.0 mm | Wire, Tube, Cable | Adjustable rolls |
Not sure which model fits your line?
Send us your material, diameter, and throughput and our application engineers will specify the right configuration.
